Engineered with resilience at its core, this door is designed to meet the stringent wind load requirements. Picture coastal businesses braving hurricanes, government facilities standing strong amidst turbulent weather, or any commercial enterprise demanding unwavering protection.
Janus Series 3400
Buy Today
Contact us today for a free estimate
Have questions?
Let’s talk about it. 817.500.5988
Engineered with resilience at its core, this door is designed to meet the stringent wind load requirements. Picture coastal businesses braving hurricanes, government facilities standing strong amidst turbulent weather, or any commercial enterprise demanding unwavering protection.
How It's Made
CONSTRUCTION DETAILS
Materials
Constructed with 24-gauge galvanized corrugated steel and Grade 80 galvanized steel, ensuring strength and resistance to harsh conditions.
Finish
It features a super-durable polyester paint coating in Satin White, which offers corrosion resistance and maintains its appearance over time.
Insulation and R-Value
Optional Series 3400 I insulation enhances thermal efficiency, reducing energy costs in climate-controlled environments.
Warranty
Janus offers a comprehensive warranty package, including a one-year warranty on all door components, a 40-year film integrity warranty, and up to a 30-year chalk and fade warranty on the paint coatings.
Safety
Equipped with low friction, grease-filled steel ball bearings and a robust guide system to ensure safe and smooth operation.
Additional
Includes flexible nylon wear strips, vinyl guide wear strips, and various custom options to meet specific functional needs.
Make It Your Own
DESIGN DETAILS
Features a curtain constructed from robust 24-gauge galvanized corrugated steel, ensuring strength and durability. The curtain is further enhanced with flexible nylon wear strips that minimize friction and noise during operation.
Choose from various operational styles to suit your needs. The 3400 offers push-up, hand chain, and electric operation options, providing flexibility for different environments and preferences.
Bottom bar of the 3400 is crafted from 24 gauge acrylic-coated galvalumed roll-formed steel and reinforced with a 2” x 1 ½” galvanized angle, creating a sturdy foundation for the door.
While the 3400's standard finish is a classic Satin White, the door boasts super durable polyester paint coatings that resist corrosion. It comes with a 40-year film integrity warranty and up to a 30-year chalk and fade warranty.
Learn More
FREQUENTLY ASKED QUESTIONS
What is the maximum opening size for the Janus Series 3400 Commercial Sheet Doors?
The Janus Series 3400 Commercial Sheet Doors are designed to accommodate openings up to 12 feet wide and 16 feet high, with a maximum total area of 192 square feet. This size range is well-suited for many commercial applications, such as storefronts, warehouses, and garages, where large openings are required for easy access and the movement of goods or vehicles.
What are the PSF ratings for the Series 3400 doors?
The Janus Series 3400 Commercial Sheet Doors have been engineered to withstand the high wind pressures specified by the stringent building codes of Miami-Dade County, Florida. These doors boast impressive PSF (pounds per square foot) ratings of +43 PSF and -49 PSF. The positive PSF rating indicates the door’s resistance to inward-acting wind pressure, while the negative PSF rating represents its ability to withstand outward-acting wind pressure.
Is insulation available for the Series 3400 doors?
Yes, the Janus Series 3400 Commercial Sheet Doors can be upgraded to the insulated Series 3400i for enhanced energy efficiency and temperature control. The Series 3400i features a layer of insulation material within the door curtain, which helps to minimize heat transfer between the interior and exterior of the building. This insulation upgrade is particularly beneficial for applications where maintaining a consistent interior temperature is crucial, such as climate-controlled storage facilities, refrigerated warehouses, or buildings with HVAC systems.
